Wiring devices / Traditional wiring devices / ARKÉ / Mounting frames
Frame 1M for panel mounting
1-module mounting frame, with screws, for panel mounting
产品状态
3 - Active
您可能也感兴趣
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
1
1
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
最小订单数量: 10 NR
条形码
8007352453258
1 NR
3.4x7.9x1 [cm]
9.5 [g]
8007352453265
10 NR
13.9x11.9x7.4 [cm]
138 [g]
8007352637665
200 NR
38.5x29.5x25 [cm]
3,060 [g]
