20026.PLS
Wiring devices / Traditional wiring devices / EIKON / Buttons
Button 1M +diffuser PLS symb.grey
Interchangeable 1-module button, with lightable diffuser, Please Clean customization, grey
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Control element/cover plate for domestic switching devices
Model
One-part rocker
One-part rocker
Imprint/indication
Characters ˝0-1˝
Characters ˝0-1˝
Utilization
Switch/push button
Switch/push button
Suitable for touch sensor connector for bus system
No
No
Type of fastening
Clamp mounting
Clamp mounting
Monitoring window/light outlet
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Grey
Grey
RAL-number (similar)
7024
7024
With label area
No
No
With exchangeable lens/symbol
No
No
Suitable for degree of protection (IP)
IP40
IP40
Width
22,00 mm
22,00 mm
Height
44,20 mm
44,20 mm
Depth
6,00 mm
6,00 mm
00. CE Marking - EU
最小订单数量: 5 NR
条形码
8007352540521
1 NR
2.2x4.4x0.6 [cm]
3.312 [g]
8007352540538
5 NR
4.1x2.8x5.3 [cm]
16.56 [g]
8007352540545
25 NR
14.2x6.7x5.9 [cm]
114.45 [g]
