20597.N
Wiring devices / View Wireless wiring devices / EIKON / Devices
IoT connected gateway 2M Next
View Wireless gateway, Bluetooth® wireless technology 4.2 Wi-Fi, RGB LED, 100-240 V 50/60 Hz power supply, Next - 2 modules
产品状态
3 - Active
19. NOM - Mexico
29. QCERT - Colombia
37. Marking - Morocco
37. Marking - Morocco
40. Bluetooth technology
41. Wi-Fi CERTIFIED
43. UKCA mark - Great Britain
92. RoHS UAE
| 问题： | How many devices can I install in a Wireless system? |
|---|---|
| 回答： | The system allows the configuration of a maximum of 64 devices for each gateway code 14597-16497-19597-20597 |
| 问题： | Which App is dedicated to system configuration? |
| 回答： | The system can be configured using the View Wireless App. |
| 问题： | Is gateway code 14597-16497-19597-20597 compulsory or can I install it and remove it at a later date? |
| 回答： | To allow the system to be managed via the VIEW App, the presence of gateway code 14597-16497-19597-20597 is compulsory. |
| 问题： | In which App can you create system scenarios? |
| 回答： | Solely in the VIEW App |
| 问题： | If I use gateway code 14597-16497-19597-20597, should the devices be configured in BLE or in Zigbee technology? |
| 回答： | In the presence of gateway code 14597-16497-19597-20597, the devices have to work in BLE mode (default mode) |
| 问题： | How do you reset the devices? |
| 回答： | Resetting is done by pressing the configuration push button for a prolonged amount of time, which must be done within 5 min of commissioning (powering) the product. |
| 问题： | Is an Internet connection necessary to transfer the connected system from the installer to the administrator (system delivery)? |
| 回答： | Yes, the presence of a general-purpose Internet connection is necessary, but you do not necessarily have to be in the same WiFi network in which the gateway is configured. |
| 问题： | Is Energy meter art.02963 compatible/configurable with Zigbee technology? |
| 回答： | Product 02963 is not designed to support Zigbee technology. Operation is envisaged solely for BLE technology, so it needs the dedicated system gateway code 14597-16497-19597-20597. |
| 问题： | To control a roller shutter via App, do I only need the module code 14594-16494-19594-20594 with the gateway art. 14597-16497-19597-20597? |
| 回答： | The control is designed to control the roller shutter/slat using the on-board keys and via a wireless connection. The device has the possibility of being controlled with two different radio standards (exclusive to one another): Bluetooth mesh (default) or Zigbee. The Bluetooth mesh network implies the presence of gateway 20597-19597-16497-14597 and management will occur via the VIEW App, whereas when using Zigbee technology a Zigbee 3.0 gateway is required (such as Amazon Echo Plus, Echo Show or Echo Studio) with related management via Amazon App. |
| 问题： | Using the Alexa assistant, fitted with Zigbee hub, can I control the Vimar connected 1-way switch via the Amazon App or do I also need the gateway art. 14597-19597-20597-16497? |
| 回答： | If you want to use the IoT connected simple actuator or roller shutters with Alexa (fitted with built-in ZigBee Hub), you do not need the Vimar gateway as the configuration and management of our products will be governed directly by Alexa’s ZigBee hub via the dedicated Amazon App; |
| 问题： | Does the Internet cable have to be connected? |
| 回答： | The gateway does not require a wired connection, the device uses the Bluetooth communication protocol and Wi-Fi to communicate with the devices and with the Cloud. |
找不到您想要的答案吗？
