Classic plate 8M Bright anthracite - 20668.C12

Pdf
Vimar - 20668.C12 - Classic plate 8M Bright anthracite
Vimar - 20668.C12 - Classic plate 8M Bright anthracite

20668.C12
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Classic plate 8M Bright anthracite
8 (4+4)-module Classic cover plate, Bright varnished metal and chromed frame, metallic anthracite

产品状态
2 - Will be discontinued

您可能也感兴趣

21618
21618 - Frame 8M with screws

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
8
Mounting direction
Horizontal and vertical
Number of units horizontal
4
Number of units vertical
2
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
2
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Anthracite
RAL-number (similar)
7022
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
142,30 mm
Height
155,80 mm
Depth
10,00 mm
Built-in width
142,30 mm
Built-in height
155,80 mm
Diameter bore hole (opening)
0 mm

29. QCERT - Colombia

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352480179
1 NR
18.5x18.5x2.2 [cm]
254 [g]
