Plate 4M (2+2) 71mm polished gold - 21643.09

Pdf
Vimar - 21643.09 - Plate 4M (2+2) 71mm polished gold
Vimar - 21643.09 - Plate 4M (2+2) 71mm polished gold

21643.09
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Plate 4M (2+2) 71mm polished gold
4-module cover plate (2+2, 71 mm distance between centres), Esclusivi refined aluminium, polished gold

产品状态
2 - Will be discontinued

您可能也感兴趣

21603
21603 - Frame 2M without screws 71mm
21643.G09
21643.G09 - Plate 4M (2+2) 71mm polished gold

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
4
Mounting direction
Horizontal and vertical
Number of units horizontal
4
Number of units vertical
1
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Aluminium
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Gold
RAL-number (similar)
1036
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
95,40 mm
Height
166,40 mm
Depth
9,60 mm
Built-in width
95,40 mm
Built-in height
166,40 mm
Diameter bore hole (opening)
0 mm

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352436220
1 NR
16.8x9.7x1.7 [cm]
113.3 [g]
Barcode Qty 5 NR
8007352436237
5 NR
17.7x10.3x10.7 [cm]
625.7 [g]
