30784.G
System infrastructure / Enclosures and control units / Connector block boxes / Desktop
Table mounting box 4M black
Tilted table mounting box, with variable height, for the installation of 4 modules, black. In the lowered version, connector blocks with a maximum depth of 32 mm can be installed. If you turn the cover the maximum depth extends to 44 mm. The socket outlet with USB, 30210.USB, cannot be installed. To be completed with mounting frame and cover plate.
产品状态
3 - Active
您可能也感兴趣
Class group
Domestic switching devices
Domestic switching devices
Class
Surface mounted box for flush-mounted switching equipment
Surface mounted box for flush-mounted switching equipment
Assembly arrangement
Other
Other
Suitable for modular domestic switching devices
Yes
Yes
Number of modules (module system)
4
4
Number of units
4
4
Mounting direction
Horizontal
Horizontal
Shape
Rectangular
Rectangular
Desktop device
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Black
Black
RAL-number (similar)
7021
7021
Transparent
No
No
With cover frame
No
No
Cross-trunking mounting
No
No
With duct entry
No
No
With cable entry
Yes
Yes
With screw gland entry
No
No
With installation tube entry
No
No
Shock resistant
Yes
Yes
Degree of protection (IP)
IP20
IP20
Width
147,9 mm
147,9 mm
Height
67,5 mm
67,5 mm
Depth
83,1 mm
83,1 mm
Device width
147,90 mm
147,90 mm
Device height
67,50 mm
67,50 mm
Device depth
83,10 mm
83,10 mm
Compliant with BS 4662
No
No
最小订单数量: 8 NR
条形码
8007352715981
1 NR
15x7x8.5 [cm]
191.7 [g]
8007352715998
8 NR
35x29.8x9.2 [cm]
1,720.6 [g]
