High-resistance cover for V70004 - V70104

Pdf
V70104

Enclosures and mounting boxes / Junction flush mounting boxes / Covers

High-resistance cover for V70004
Highly impact resistant cover (20 J) for junction box V70004, white

产品状态
3 - Active

您可能也感兴趣

Class group
Connection devices
Class
Cover for box/housing for built-in mounting in the wall/ceiling
Diameter
0 mm
Length
118,00 mm
For box-/housing length
92,00 mm
Width
179,00 mm
For box-/housing width
154 mm
Depth
5,30 mm
Shape
Rectangular
Type of fastening
Cover for screw mounting
Model
Blind cover
Material
Plastic
Halogen free
Yes
Colour
White
With screws
Yes
Sealable
No
最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352082120
1 NR
17.9x11.8x0.6 [cm]
51.62 [g]
Barcode Qty 10 NR
8007352084407
10 NR
17.9x11.8x6 [cm]
516.2 [g]
Barcode Qty 60 NR
8007352084414
60 NR
35x22.5x15.5 [cm]
3,331.93 [g]
