Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Contacts
1 make contact (NO)
Number of poles
1
Feedback-signal contact
No
Number of rockers
1
Number of modules (module syst
2
With lighting
Yes
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (akin)
9003
Transparent
No
Label space/information surfac
Yes
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
10,00 A
Width of device
44,80 mm
Height of device
47,00 mm
Depth of device
35,90 mm
