RGB dimmer 230V Next - 20138.N

Pdf
20138.N

Eikon Next / Devices / Electronic devices

RGB dimmer 230V Next
RGB dimmer 230 V~ 50 Hz for: RGB LED lamps, RGB LED electronic transfomers (01876), ON/OFF and brightness control with built-in push button or from peripheral NO push buttons, colour control via rotary potentiometer, visible in darkness, Next. Not for Isoset enclosures

Product Status
3 - Active

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Turn button
Type of load
Other
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 v
Frequency
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 v
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
61,00 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

31. TISI - Thailand

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352468986
1 NR
5.2x3.9x6.2 [cm]
60 [g]
Barcode Qty 5 NR
8007352468993
5 NR
14.4x11.6x6 [cm]
343.4 [g]
