Interruptor 1P 16AX 2M blanco - 09001.2

Pdf
09001.2

Neve Up / Dispositivos / Dispositivos de mando básicos

Interruptor 1P 16AX 2M blanco
Interruptor 1P 16 AX 250 V~, blanco - 2 módulos. Máx 200 W para lámparas con balasto integrado

Estado producto
3 - Activo

Podría interesarte también

Dibujos

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
47,00 mm
Depth of device
35,90 mm
Built-in depth
23,10 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

13. SNI - Indonesia

19. NOM - México

29. QCERT - Colombia

37. Marcado - Marruecos

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352296640
1 NR
5,1x4,3x5,3 [cm]
30,8 [g]
Barcode Qty 20 NR
8007352296657
20 NR
26,9x11,6x9 [cm]
697,6 [g]
Barcode Qty 240 NR
8007352296664
240 NR
37x28x34,5 [cm]
8.913,2 [g]
