Vimar - 09008.2.CM - 1P NO 10A 2M push button carbon matt

09008.2.CM

Neve Up / Devices / Basic devices

1P NO 10A 2M push button carbon matt
1P NO 10 A 250 V~ push button, Carbon Matt - 2 modules

产品状态
3 - Active

您可能也感兴趣

09008.CM - 1P NO 10A push button carbon matt

09001.2.CM - 1P 16AX 1-way switch 2M carbon matt

09005.2.CM - 1P 16AX 2-way switch 2M carbon matt

09013.2.CM - 1P 16AX reversing switch 2M carbon matt

09050 - 1P NO 10A name-plate push button white

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push-switch button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
2

Number of poles
1

Nominal voltage
250 v

Rated current
10,00 A

Feedback-signal contact
No

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Anti-bacterial treatment
No

Surface protection
Lacquered

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7016

Transparent
No

Label space/information surface
Yes

Width of device
44,90 mm

Height of device
47,00 mm

Depth of device
35,90 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352658103

1 NR

5.1x4.3x5.3 [cm]

30.8 [g]

8007352658110

20 NR

26.9x11.6x9 [cm]

698.8 [g]

8007352658127

240 NR

38x28.5x35.5 [cm]

8,927.6 [g]
