1P NO 10A push button carbon matt - 09008.CM

Pdf

Vimar - 09008.CM - 1P NO 10A push button carbon matt

09008.CM

Neve Up / Devices / Basic devices

1P NO 10A push button carbon matt
1P NO 10 A 250 V~ push button, Carbon Matt

产品状态
3 - Active

您可能也感兴趣

09008.2.CM - 1P NO 10A 2M push button carbon matt

09001.CM - 1P 16AX 1-way switch carbon matt

09005.CM - 1P 16AX 2-way switch carbon matt

09013.CM - 1P 16AX reversing switch carbon matt

09050 - 1P NO 10A name-plate push button white

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push-switch button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
1

Number of poles
1

Nominal voltage
250 v

Rated current
10,00 A

Feedback-signal contact
No

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Anti-bacterial treatment
No

Surface protection
Lacquered

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7016

Transparent
No

Label space/information surface
Yes

Width of device
22,60 mm

Height of device
47,00 mm

Depth of device
35,90 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352657823

1 NR

4.1x2.8x5.3 [cm]

23.4 [g]

8007352657830

50 NR

21.4x11.6x14.2 [cm]

1,270 [g]

8007352657847

500 NR

57.5x22x29.5 [cm]

13,300 [g]
