Vimar - 14029 - Button 1M +name-plate white

14029
Wiring devices / Traditional wiring devices / PLANA / Buttons

Button 1M +name-plate white
Interchangeable 1-module button, with lightable ring pilot lamp and name plate, white

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Control element/cover plate for domestic switching devices

Model
One-part rocker

Imprint/indication
None

Utilization
Switch/push button

Suitable for touch sensor connector for bus system
No

Type of fastening
Clamp mounting

Monitoring window/light outlet
Yes

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

With label area
Yes

With exchangeable lens/symbol
No

Suitable for degree of protection (IP)
IP40

Depth
790,00 mm

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

8007352119345

1 NR

2.22x4.37x0.8 [cm]

2.8 [g]

8007352119444

5 NR

4.1x2.8x5.3 [cm]

17.8 [g]

8007352119352

50 NR

14.4x9x6 [cm]

213.07 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
