Vimar - 16226 - 2P+E 10A Swiss 13 type outlet grey

16226
Wiring devices / Traditional wiring devices / IDEA / Devices

2P+E 10A Swiss 13 type outlet grey
2P+E 10 A 250 V~ socket outlet, Swiss standard, 13 type, grey

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Socket outlet

Model
Swiss norm type 13

Number of units
1

Number of modules (module system)
1

Number of socket outlets switchable
0

Imprint/indication
None

Connection type
Screwed terminal

With hinged lid
No

With enhanced contact protection
No

Label space/information surface
Yes

Colour
Grey

RAL-number (similar)
7015

Metallic colour
No

Transparent
No

Lockable
No

Eject-mechanism
No

Insulated mounting
No

With function lighting
No

Over voltage protection
No

Fault current protection
No

Mounting method
Flush-mounted

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

With loop through function
No

With on/off switch
No

Rotated central insert
No

Nominal current
10 A

Nominal voltage
250 V

Frequency
50,00 - 60,00 HZ

Suitable for degree of protection (IP)
IP20

Impact strength
Other

Device width
24,80 mm

Device height
50,10 mm

Device depth
49,80 mm

00. CE Marking - EU

05. SEV - Switzerland

10. EAC Eurasian Customs Union

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352084810

1 NR

5.1x2.8x5.3 [cm]

36.44 [g]

8007352084827

20 NR

27x11.6x6 [cm]

795.4 [g]

8007352651173

120 NR

37.5x30x13.5 [cm]

5,100 [g]
