Blank module smooth front grey - 16542

Pdf
Vimar - 16542 - Blank module smooth front grey
Vimar - 16542 - Blank module smooth front grey

16542
Wiring devices / Traditional wiring devices / IDEA / Blank module

Blank module smooth front grey
Blank cover, smooth front, grey

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Push button
Method of operation
Other
Number of modules (module system)
100
Nominal voltage
0 V
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Mounting with claw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Device width
24,80 mm
Device height
50,20 mm
Device depth
20,50 mm

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 100 NR

条形码

Barcode Qty 1 NR
8007352082359
1 NR
2.5x5x2 [cm]
5.77 [g]
Barcode Qty 10 NR
8007352146051
10 NR
31x5.2x2 [cm]
58.2 [g]
Barcode Qty 100 NR
8007352083431
100 NR
28.2x11.1x10 [cm]
677.8 [g]
Barcode Qty 1,000 NR
8007352262782
1,000 NR
57.5x22.5x30 [cm]
7,329.33 [g]
Barcode Qty 21,000 NR
8007352308596
21,000 NR
80x120x103 [cm]
167,000 [g]
