IoT connected dimmer mechanism 220-240V - 20595.0

Pdf

Vimar - 20595.0 - IoT connected dimmer mechanism 220-240V

20595.0
Wiring devices / View Wireless wiring devices / EIKON / Devices

IoT connected dimmer mechanism 220-240V

Compatible with both LE and TE dimmable lamps
Also configurable as a 1-way switch pending the installation of a dimmable lamp
Bluetooth mode compatible with Amazon Alexa, Google Assistant, Apple Homekit and IFTTT voice assistants, via the dedicated Vimar gateway
Zigbee mode compatible with the Amazon Alexa voice assistant, via Amazon Zigbee hub

产品状态
3 - Active

您可能也感兴趣

20755.3 - 2 half buttons 1M dimmer grey

20755.3.B - 2 half buttons 1M dimmer white

20755.3.N - 2 half buttons 1M dimmer Next

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Other

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7024

Label space/information surface
No

Illumination
Yes

Function lighting
Other

Type of lighting
LED not exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
240 V

Feedback-signal contact
No

Connection type
Screwed terminal

Heating switch
No

Washing machine switch
No

Device width
22,30 mm

Device height
49,00 mm

Device depth
46,90 mm

Built-in depth
37,50 mm

Min. depth of built-in installation box
42,00 mm

Compatible with Apple HomeKit
Yes

Compatible with Google Assistant
Yes

Compatible with Amazon Alexa
Yes

IFTTT support available
Yes

00. CE Marking - EU

01. IMQ - Italy

06. SUBTEL - Chile

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352707993

1 NR

6x5.4x5.2 [cm]

44.3 [g]

8007352708006

60 NR

37.5x30x13.5 [cm]

3,150.6 [g]
