Vimar - 20657.G24 - Classic plate 7M Galvan.polished gold

20657.G24
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Classic plate 7M Galvan.polished gold
7-module Classic cover plate, Refined metal and with golden frame, polished gold

产品状态
2 - Will be discontinued

您可能也感兴趣

21617 - Frame 7M +screws

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
7

Mounting direction
Horizontal and vertical

Number of units horizontal
7

Number of units vertical
1

Number of modules horizontal (module system)
7

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Metal

Material quality
Other

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Glossy

Colour
Gold

RAL-number (similar)
1036

Transparent
No

With hinged lid
No

Degree of protection (IP)
IP00

Type of fastening
Clamp mounting

Width
206,00 mm

Height
85,00 mm

Depth
9,00 mm

Built-in width
206,00 mm

Built-in height
85,00 mm

Diameter bore hole (opening)
0 mm

29. QCERT - Colombia

最小订单数量: 1 NR

条形码

8007352484191

1 NR

21.75x9.5x1.6 [cm]

210.5 [g]

8007352484207

5 NR

22.6x10.2x10.2 [cm]

1,108 [g]

合法
