VIMAR handfree S.S. voice unit interface - 6560

Pdf

6560
ELVOX Door entry system / Multi-wire video entry system / Shared A/V components / System components

VIMAR handfree S.S. voice unit interface
Module for Sound System 0931 and 6680 power supply unit audio interfacing with VIMAR speakerphone interphones, power supply 15-21 Vd.c., installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

Product Status
9 - Discontinued

Question: Is the 6560 Speakerphone also used for the Elvox DigiBUS and Due Fili video door entry modules?
Answer: No, it is only required for Sound System technology with intercoms (part no. 20555 - 20555.N - 20555.B - 14555 - 14555.SL).
Question: What is the 6560 Speakerphone and what is it for? Does it always have to be installed with the Vimar intercom in Sound System?
Answer: The ELVOX part no. 6560 serves to integrate Vimar Intercoms (part no. 20555 - 20555.N - 20555.B - 14555 - 14555.SL) in Sound System and should be installed as close as possible to the Elvox power supply, connecting it according to the wiring schemes provided and upstream of the other devices installed.

Didn't find the answer you were looking for?

Ask a question

Share

Codice QR scheda articolo
