Home automation module 3IN 3OUT LEDCode 01475
- 01475
- Smart systems&products / By-me Plus / Shared components / Non-modular components
- Home automation module 3IN 3OUT LED
- Module with 3 programmable digital inputs for contacts without potential, 3 LED control outputs, By-me home automation, flush mounting at the back of the device
- Product Status
- 3 - Active
You may also be interested in
Sheets, Manuals, Documentation
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Basic module for bus system
Basic module for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Mounting method
DRA (DIN-rail adaptor)
DRA (DIN-rail adaptor)
Width in number of modular spacings
0
0
Local operation/hand operation
No
No
Number of inputs
3
3
Number of outputs
3
3
Degree of protection (IP)
IP20
IP20
With bus connection
Yes
Yes
00. CE Marking - EU
01. IMQ - Italy
37. Marking - Morocco
92. RoHS UAE
Minimum order quantity: 10 NR
Barcode
8007352539433
1 NR
5.7x5.3x7.7 [cm]
38.2 [g]
8007352733169
70 NR
39.5x30x17 [cm]
3,012 [g]
| Question: | If retrofitted, can the lighting of a group of lamps via push button/traditional 1-way switch be transferred onto the By-me bus? |
|---|---|
| Answer: | Product art. 01475 can receive the voltage-free contact from a traditional control in input (both a push button and a 1-way switch, simply specify the related option during configuration) and propagate the control towards the home automation system actuator to which the load to manage is connected on the By-me home automation system BUS. |
