SLAVE dimmer 230V 800W/VACode 01864

Download as PDFPDF

01864: Smart systems&products / By-me Plus / Shared components / DIN devices
SLAVE dimmer 230V 800W/VA: SLAVE dimmer, 230 V~, for: 40-800 W to 50 Hz, 40-700 W to 60 Hz incandescent lamps, 40-800 VA to 50 Hz, 40-700 VA to 60 Hz ferromagnetic transformers, control from 01863, MOSFET+TRIAC technology, protection fuse, for DIN (60715 TH35) rail installation, occupies 4 17,5 mm modules
Product Status: 2 - Will be discontinued

Sheets, Manuals, Documentation

FI - Foglio istruzioni ZIS_49400256A0 (281 kb)

Drawings

Class group
Installation bus systems

Class
Dimming actuator for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequency)
No

Bus system radio frequency
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
Other

Radio frequency bidirectional
No

Model
Dimming actuator

Mounting method
Other

Width in number of modular spacings
4

With bus connection
No

Bus module detachable
No

Local operation/hand operation
No

With LED indication
Yes

Number of outputs
1

Output power
40 - 800 W

Power boost suitable
Yes

Type of load
Universal

Voltage
230,00 - 230,01 V

Parallel-service possible
No

Frequency
50,00 - 60,00 HZ

Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

8007352387454

11.7x10.8x7.1 [cm]

199.6 [g]
