03809
Safety / By-alarm Plus / Surface mounting components / Non-modular components
By-alarm Plus relay interface board
By-alarm Plus relay interface board, 12 VDC 30 mA power with negative connected to an OC output from an expansion or control unit zone, one 28 VDC 7 A changeover output.
Product Status
3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Expansion module for danger detection system
Expansion module for danger detection system
Mounting method
Built-in
Built-in
Housing material
Aluminium
Aluminium
Colour
Brown
Brown
Height
34,00 mm
34,00 mm
Width
46,00 mm
46,00 mm
Depth
21,90 mm
21,90 mm
Minimum order quantity: 1 NR
Barcode
8007352707320
1 NR
6x2.8x5.3 [cm]
29.92 [g]
8007352707337
20 NR
28.1x13.1x6 [cm]
679.5 [g]
8007352707344
240 NR
38.5x29x30 [cm]
8,634 [g]
