2P 16AX 1-way switch - 08016

Pdf
08016

8000 / Devices / Basic devices

2P 16AX 1-way switch
2P 16 AX 250V~ 1-way switch. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Cream white (electro white)
RAL-number (akin)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
22,00 mm
Height of device
50,10 mm
Depth of device
35,50 mm
Built-in depth
24,00 mm
Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352013827
1 NR
4.1x2.8x5.3 [cm]
29.73 [g]
Barcode Qty 50 NR
8007352006454
50 NR
21.4x11.6x14.2 [cm]
1,574 [g]
Barcode Qty 500 NR
8007352641396
500 NR
57.5x22.5x30 [cm]
16,770 [g]
