2P+E 15A USA+SASO outlet - 08195

Pdf
08195

8000 / Devices / Other standards socket outlets

2P+E 15A USA+SASO outlet
2P+E 15 A 127 V~ socket outlet, American and Saudi Arabian standards

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
American National Standard
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Height of device
45,00 mm
Depth of device
37,50 mm
Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352014282
1 NR
4.1x2.8x5.3 [cm]
29.6 [g]
Barcode Qty 50 NR
8007352016576
50 NR
21.4x11.6x14.2 [cm]
1,561.13 [g]
