1P 10AX 1-way switch +key - 08384

Pdf
08384

8000 / Devices / Devices - other functions

1P 10AX 1-way switch +key
1P NO + 1P NC 10 AX 250 V~ key-operated 1-way switch

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Key
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Height of device
45,00 mm
Depth of device
43,00 mm
Built-in depth
33,50 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352014886
1 NR
6x2.8x5.3 [cm]
48.73 [g]
Barcode Qty 20 NR
8007352016897
20 NR
28.1x13.1x6 [cm]
1,056.07 [g]
