Button 1M bell symbol white - 09021.C

Pdf
Vimar - 09021.C - Button 1M bell symbol white
Vimar - 09021.C - Button 1M bell symbol white
09021.C

Neve Up / Devices / Basic devices

Button 1M bell symbol white
1-module interchangeable button, lighTable bell symbol, white

Product Status
3 - Active

You may also be interested in

09021.C
09021.C - Button 1M bell symbol white
09005.0.250
09005.0.250 - 1P 16AX 2-way switch mechan.+pilot250V
09008.0.250
09008.0.250 - 1P NO 10A push button mechan.+pilot 250V
09008.0.12
09008.0.12 - 1P NO 10A push button mechan.+pilot 12V

Drawings

view encumbered art. 09021.C
PNG DXF
rear view art. 09021.C
PNG DXF
3D view art. 09021.C
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
Single rocker
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
With exchangeable lens/symbol
Yes
Depth
750 mm

00. CE Marking - EU

29. QCERT - Colombia

29. QCERT - Colombia

43. UKCA mark - Great Britain

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352659179
1 NR
2.2x4.4x1.1 [cm]
6.37 [g]
Barcode Qty 5 NR
8007352659186
5 NR
5.1x2.8x5.3 [cm]
24.31 [g]
Barcode Qty 50 NR
8007352659193
50 NR
14.4x11.6x6 [cm]
283.5 [g]
Barcode Qty 600 NR
8007352668645
600 NR
36.5x33x13.5 [cm]
3,822 [g]
