2P 16A USA+EU ø4,8mm SICURY outlet white - 09234

09234

Neve Up / Devices / Other standards socket outlets

2P 16A USA+EU ø4,8mm SICURY outlet white
2P 16 A 250 V~ SICURY socket outlet, polarized Euro-American standard (parallel and in-line flat blades and ø 4,8 mm blades), white

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
With built-in USB power supply
No
Number of modules (module syst
1
Number of socket outlets switc
0
Imprint/indication
Without imprint
Connection type
Screwed terminal
With hinged lid
No
With child-protection
Yes
Label space/information surfac
Yes
Colour
White
RAL-number (akin)
9003
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protect
IP20
For heavy conditions (in accor
No
Impact strength
Other
Width of device
22,30 mm
Height of device
47,00 mm
Depth of device
39,50 mm
Minimum order quantity: 50 NR

Barcode

8007352296824
1 NR
4.1x2.8x5.3 [cm]
28 [g]
8007352296831
50 NR
21.4x11.6x14.2 [cm]
1,487 [g]
8007352296848
500 NR
57.5x22.5x30 [cm]
15,392 [g]
