2P+E 16A P17/11 outlet - 10145

Pdf
Vimar - 10145 - 2P+E 16A P17/11 outlet
Vimar - 10145 - 2P+E 16A P17/11 outlet

10145
Wiring devices / Traditional wiring devices / LINEA Classica / Devices

2P+E 16A P17/11 outlet
2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
With hinged lid
No
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Device width
22,00 mm
Device height
36,00 mm
Device depth
32,50 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352020276
1 NR
4.1x2.8x5.3 [cm]
27.3 [g]
Barcode Qty 50 NR
8007352007482
50 NR
21.4x11.6x14.2 [cm]
1,442.87 [g]
Barcode Qty 500 NR
8007352717008
500 NR
57.5x22.5x30 [cm]
14,430 [g]
