Self-bearing plate 1M for ø60mm box - 10705

Pdf
Vimar - 10705 - Self-bearing plate 1M for ø60mm box
Vimar - 10705 - Self-bearing plate 1M for ø60mm box
10705

Linea Classica / Cover plates / Self-bearing cover plates

Self-bearing plate 1M for ø60mm box
1-module self-bearing cover plate, resin, with claws for round mounting boxes ø 60 mm, ivory, delivered with screw covering strips 10797.01

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
1
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
Number of switch inserts
0
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9003
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
98,00 mm
Height
76,00 mm
Built-in width
98,00 mm
Built-in height
76,00 mm
Diameter bore hole (opening)
0 mm

01. IMQ - Italy

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352044005
1 NR
9.8x7.6x1.5 [cm]
32.4 [g]
Barcode Qty 20 NR
8007352010147
20 NR
28.1x13.1x11.3 [cm]
752.87 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
