Self-bearing plate 2M for ø60mm box - 10706

Pdf
10706

Linea / Cover plates / Self-bearing cover plates

Self-bearing plate 2M for ø60mm box
2-module self-bearing cover plate, resin, with claws for round mounting boxes ø 60 mm, ivory, delivered with screw covering strips 10798.01

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
Number of switch inserts
0
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9003
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
98,00 mm
Height
76,00 mm
Built-in width
98,00 mm
Built-in height
76,00 mm
Diameter bore hole (opening)
0 mm

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352044012
1 NR
9.8x7.6x1.5 [cm]
30.87 [g]
Barcode Qty 20 NR
8007352004351
20 NR
28.1x13.1x11.3 [cm]
729.8 [g]
