2P+E 16A P17/11 outlet +C16 CB Silver - 14273.SL

Pdf
14273.SL

Plana Silver / Devices / Protected socket outlets

2P+E 16A P17/11 outlet +C16 CB Silver
2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11, interlocked with 1P+N C 16 circuit breaker, supply voltage 230 V~ 50 Hz, breaking capacity 3000 A, Silver - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type Bipasso
With built-in USB power supply
No
Number of units
2
Number of modules (module system)
2
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Silver
RAL-number (similar)
9006
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
With miniature fuse
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
With on/off switch
Yes
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
230 v
Frequency
50,00 - 50,01 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
56,30 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352318793
1 NR
6x5.4x5.3 [cm]
97.09 [g]
Barcode Qty 5 NR
8007352318809
5 NR
17.2x13.1x6 [cm]
544.4 [g]
