TV-FM-SAT single conn. 3outs whiteCode 14303

Download as PDFPDF

14303: Wiring devices / Traditional wiring devices / PLANA / Devices
TV-FM-SAT single conn. 3outs white: Coaxial TV-FM radio-SAT 5-2400 MHz socket outlet, single connection, demix, 3 outputs with TV male and female FM radio and F-type (SAT) connectors, connection attenuation 1 dB, white - 2 modules. Allows the passage of d.c. current and control signals (24 V 500 mA max) through the female connector
Product Status: 3 - Active

Sheets, Manuals, Documentation

Multilanguage instructions sheet (506 kb)

Drawings

Class group
Antenna and satellite technique

Class
Antenna socket box

Model
End socket

Tap loss at 860 MHz
1,80 dB

Tap loss at 2150 MHz
1,30 dB

Number of outlets
3

Suitable for remote power supply
Yes

Type of fastening
Snap mounting (engagement)

Colour
White

RAL-number (similar)
9003

Material
Plastic

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 5 NR

Barcode

8007352395046

5.1x4.3x5.3 [cm]

81.6 [g]

8007352395053

14.4x11.6x6 [cm]

456.6 [g]

8007352637443

60 NR

36.5x33x13.5 [cm]

5,779.2 [g]
