2P 16AX 1-way switch grey - 16016

Pdf
16016

Idea / Devices / Basic devices

2P 16AX 1-way switch grey
2P 16 AX 250 V~ 1-way switch, grey. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
24,80 mm
Height of device
50,10 mm
Depth of device
46,00 mm
Built-in depth
32,50 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

19. NOM - Mexico

20. IRAM - Argentina

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352000438
1 NR
5.1x2.8x5.3 [cm]
35.87 [g]
Barcode Qty 20 NR
8007352001275
20 NR
27x11.6x6 [cm]
785.13 [g]
Barcode Qty 120 NR
8007352642188
120 NR
37.5x30x13.5 [cm]
5,256 [g]
