2P+E 15A 127V USA outlet grey - 16245

Pdf
Vimar - 16245 - 2P+E 15A 127V USA outlet grey
Vimar - 16245 - 2P+E 15A 127V USA outlet grey
16245

Idea / Devices / Other standards socket outlets

2P+E 15A 127V USA outlet grey
2P+E 15 A 127 V~ socket outlet, American and Saudi Arabian standards, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
American National Standard
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
24,80 mm
Height of device
74,80 mm
Depth of device
37,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

19. NOM - Mexico

20. IRAM - Argentina

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352025172
1 NR
4.1x2.8x5.3 [cm]
30.07 [g]
Barcode Qty 20 NR
8007352025189
20 NR
21.4x11.6x6 [cm]
659.67 [g]
Barcode Qty 460 NR
8007352626195
460 NR
57.5x22.5x30 [cm]
15,560 [g]
