Classica plate 3M metal polished gold - 16733.32

Pdf
16733.32

Idea / Cover plates / Metal Classica cover plates

Classica plate 3M metal polished gold
3-module Classica cover plate, die-cast metal, polished gold

Product Status
3 - Active

You may also be interested in

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
Number of switch inserts
0
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Gold
RAL-number (similar)
1036
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
120,00 mm
Height
82,00 mm
Depth
9,25 mm
Built-in width
120,00 mm
Built-in height
82,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352033641
1 NR
12.5x8.5x1.1 [cm]
118.32 [g]
Barcode Qty 10 NR
8007352000407
10 NR
13.5x12.4x9.2 [cm]
1,131.53 [g]
Barcode Qty 80 NR
8007352369030
80 NR
37.5x30x13.5 [cm]
9,412.24 [g]
Barcode Qty 160 NR
8007352703803
160 NR
50.5x20x28 [cm]
19,676 [g]
Barcode Qty 3,840 NR
8007352588158
3,840 NR
120x80x105 [cm]
479,216 [g]
Question: Are the Idea Rondo plaques compatible with the devices and mounting supports of the Idea Classic plaques?
Answer: The Idea series has devices and mounting supports that can be completed with both Classic plaques and Rondo plaques. The Rondo plaques are not compatible with the following parts (thus require Classic plaques):-16803 and 16806 table mounting box-16813 mounting bracket-09975.A surface mounting box-16570.SZ and 16570.SZ.B mounting support for infrared remote control.
