System infrastructure / Enclosures and control units / Connector block boxes / Surface mounting
Surface mounting box Idea grey
Surface mounting box, Idea grey. Dimensions: 248x146x74,5 mm
Product Status
2 - Will be discontinued
Class group
Electrical installation, isolation and connection material
Electrical installation, isolation and connection material
Class
Box/housing for surface mounting on the wall/ceiling
Box/housing for surface mounting on the wall/ceiling
Equipped with
None
None
Max. conductor cross section
0,00 mm2
0,00 mm2
Shape
Rectangular
Rectangular
Mounting method
Wall-/ceiling mounting
Wall-/ceiling mounting
For tube diameter
20/25 mm
20/25 mm
Number of inlets
6
6
Inlet from the rear
Yes
Yes
Length
146,00 mm
146,00 mm
Width
248,00 mm
248,00 mm
Depth
74,50 mm
74,50 mm
Diameter
0,00 mm
0,00 mm
Connectable
No
No
Type of housing feed-through
None
None
Material
Plastic
Plastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Colour
Grey
Grey
Degree of protection (IP)
IP20
IP20
Cover model
Other
Other
Transparent cover
No
No
Castable
No
No
Cover attachment
Screwed
Screwed
Casting compound included
No
No
Sealable
No
No
Rated insulation voltage Ui
450 V
450 V
Circuit integrity
None
None
With screening
No
No
Weatherproof
No
No
Working temperature
0 - 60 °C
0 - 60 °C
Explosion-tested version
No
No
For Ex-zone gas
None
None
For Ex-zone dust
None
None
Minimum order quantity: 1 NR
Barcode
8007352095571
1 NR
28.4x18.4x7.5 [cm]
369.73 [g]
