KNX vertical transponder reader grey - 16923

Pdf
16923

Idea / Systems / KNX - Hotel

KNX vertical transponder reader grey
Transponder card reader with vertical pocket for installation inside rooms, KNX standard, 2 NO 4 A 24 V~ relay outputs, 2 inputs, supplementary power supply 12-24 V~ 50-60 Hz and 12-24 V d.c. (SELV), grey - 3 modules

Product Status
4 - Active

Class group
Installation bus systems
Class
Access control unit for bus system
Bus system KNX
Yes
Bus system KNX radio
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Material
Plastic
Material quality
Thermoplastic
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352373556
1 NR
11.2x9.6x9.8 [cm]
160 [g]
Question: What can I control with the actuators located on the devices?
Answer: In the external transponder reader, the internal transponder reader and the thermostat, you can control a maximum load of 24V, 2A (see instruction sheets). While for the Input/Output module, the relays control a maximum 240V, 16A (see instruction sheets).

Didn't find the answer you were looking for?

Ask a question

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
