16989
Idea / Systems / Domotics - devices
Two rocker pushbuttons+MASTER actuator g
Three rocker push buttons and actuator for MASTER dimmer 230 V~ 50 Hz for: 40-300 W incandescent lamps, 40-200 VA electronic transfomers, 10-120 W CFL lamps, 3-120 W LED lamps and LED electronic transfomers, protection fuse, to complete with interchangeable 1- or 2-module buttons, grey - 3 modules
Product Status
42 - Will be discontinued
Sheets, Manuals, Documentation
Drawings
Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Contacts
Other
Number of poles
1
Feedback-signal contact
No
Number of rockers
3
Number of modules (module syst
3
With lighting
Yes
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
9001
Transparent
No
Label space/information surfac
Yes
Imprint
None
Suitable for degree of protect
IP40
Nominal voltage
230 v
Width of device
74,80 mm
Height of device
50,10 mm
Depth of device
44,95 mm
10. EAC Eurasian Customs Union
Minimum order quantity: 1 NR
Barcode
8007352458789
1 NR
11.2x9.6x9.8 [cm]
159 [g]
