1P 16AX 1-way switch grey - 17001

Pdf
17001

Idea / Reduced module devices / Basic devices

1P 16AX 1-way switch grey
1P 16 AX 250 V~ 1-way switch, grey - reduced module. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module syst
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (akin)
7015
Label space/information surfac
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
21,80 mm
Height of device
50,10 mm
Depth of device
36,50 mm
Built-in depth
23,30 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352005570
1 NR
4.1x2.8x5.3 [cm]
25.07 [g]
Barcode Qty 20 NR
8007352005587
20 NR
21.4x11.6x6 [cm]
557.4 [g]
