IR receiver + dimmer grey - 19175

Pdf
19175

Arké / Devices / Electronic devices

IR receiver + dimmer grey
Infrared receiver with dimmer, supply voltage 230 V~ 50 Hz for: 40-450 W incandescent lamps, 40-450 VA ferromagnetic transfomers and 40-300 VA inductive response electronic transformers, control and regulation with built-in push button, 01849 remote control or from NO peripheral push buttons, MASTER function, MOSFET+TRIAC technology, visible in darkness, grey

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Infrared
Type of load
Inductive load
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
Yes
Mounting method
Flush mounted (plaster)
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 v
Frequency
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 v
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
51,00 mm

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352450639
1 NR
5.1x4.3x5.3 [cm]
55 [g]
Barcode Qty 5 NR
8007352450646
5 NR
14.4x11.6x6 [cm]
324 [g]
