Switched 2P+E 13A English outlet grey - 19221

Pdf
Vimar - 19221 - Switched 2P+E 13A English outlet grey
Vimar - 19221 - Switched 2P+E 13A English outlet grey

19221
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Switched 2P+E 13A English outlet grey
2P switched 2P+E 13 A 250 V~ SICURY socket outlet, English standard, with built-in frame for square British standard mounting boxes, to complete with 3-module British standard cover plate, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
British Standard
Number of modules (module system)
3
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
Yes
Rotated central insert
No
Nominal current
13 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
82,50 mm
Device height
82,50 mm
Device depth
29,50 mm

00. CE Marking - EU

08. ASTA - UK

30. G-Mark - Gulf Countries

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352592544
1 NR
8.5x3.9x8.6 [cm]
104.9 [g]
Barcode Qty 10 NR
8007352592551
10 NR
20.7x18.5x9.6 [cm]
1,163 [g]
