19320.B
Wiring devices / Traditional wiring devices / ARKÉ / Devices
RJ11 phone jack 6/4 white
RJ11 phone jack, 6-position 4-conductor (6/4), screw terminals, white
Product Status
3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Insert/cover for communication technology
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Utilization
UAE/IAE (ISDN)
UAE/IAE (ISDN)
Support ring
No
No
With dust cover
No
No
With hinged lid
No
No
Mounting method
Flush-mounted
Flush-mounted
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9016
9016
Transparent
No
No
Type of fastening
Clamp mounting
Clamp mounting
Number of modules (module system)
1
1
With strain relief
No
No
Luster terminal
No
No
Suitable for degree of protection (IP)
IP20
IP20
Device width
22,30 mm
22,30 mm
Device height
49,00 mm
49,00 mm
Device depth
43,10 mm
43,10 mm
00. CE Marking - EU
Minimum order quantity: 20 NR
Barcode
8007352455870
1 NR
5.1x2.8x5.3 [cm]
21.6 [g]
8007352455887
20 NR
27x11.6x6 [cm]
501.3 [g]
8007352482890
120 NR
37.5x30x13.5 [cm]
3,367.8 [g]
8007352750661
5,760 NR
120x80x105 [cm]
161,660 [g]
