Domotic temperature probe MetalCode 19538.M
- 19538.M
- Smart systems&products / By-me Plus / ARKÉ / Devices
- Domotic temperature probe Metal
- Temperature probe for ambient temperature control (heating and air-conditioning), 2 and 4 pipe system management, 3-speed and proportional fan-coil control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, 1 input for flush-mounting or wired NTC temperature sensor, for By-me home automation system, can be interfaced with actuator with proportional analogue outputs 01466 to make a class V modulating room thermostat (contribution 3%), Metal
- Product Status
- 3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Stats, switches and controllers
Stats, switches and controllers
Class
Room thermostat
Room thermostat
Model
Other
Other
With receiver
No
No
External sensor
Yes
Yes
Mounting method
Flush-mounted
Flush-mounted
With display
No
No
Colour
Silver
Silver
RAL-number
9007
9007
Height
49,00 mm
49,00 mm
Width
22,30 mm
22,30 mm
Depth
50,50 mm
50,50 mm
00. CE Marking - EU
37. Marking - Morocco
Minimum order quantity: 1 NR
Barcode

8007352594531
1 NR
6x2.8x5.3 [cm]
37.6 [g]

8007352594548
10 NR
14.4x13.1x6 [cm]
426.7 [g]

8007352741157
200 NR
50.5x20x28 [cm]
8,974 [g]
