Frame 1M +claws - 19601

19601

Arké / Mounting frames / For round boxes

Frame 1M +claws
1-module mounting frame, with claws, for ø 60 mm mounting boxes

• The transparency helps the installation and the wiring of devices
• The honeycomb structure gives structural strength
• The slots in the corners enable fixing to the panel
• The hooking teeth encourage fixing in series for the installation of multiple modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data
• Questions and answers

Video

• Arké lives in your time

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush mounted (plaster)

Mounting method
Mounting with claw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for floor box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

Minimum order quantity: 20 NR

---

Barcode

8007352433441

1 NR

7.4x7.4x2.5 [cm]

24 [g]

8007352433458

20 NR

24.4x13.9x10.1 [cm]

562.2 [g]

8007352644458

80 NR

30.5x26x22 [cm]

2,804 [g]

Question:	Is the product compatible for assembly with mounting frame 19601 and cover plate 19641.74?
Answer:	Yes, article 19006.B is compatible with assembly on mounting frame 19601 and cover plate 19641.74.

---
