Frame 2M +claws 71mm - 19602

19602
Wiring devices / Traditional wiring devices / ARKÉ / Mounting frames

Frame 2M +claws 71mm
2-module mounting frame, with claws, for ø 60 mm mounting boxes, 71 mm distance between centres

• The transparency helps the installation and the wiring of devices
• The honeycomb structure gives structural strength
• The slots in the corners enable fixing to the panel
• The hooking teeth encourage fixing in series for the installation of multiple modules

Product Status
3 - Active

You may also be interested in

14602.C - Frame protection 2M Plana/Arké

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Video

• Arké lives in your time

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with claw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

43. UKCA mark - Great Britain

50. Product Environm. Profile

96. Electrotechnical expert

Minimum order quantity: 50 NR

---

Barcode

8007352433465

1 NR

7.4x7.4x2.5 [cm]

17.8 [g]

8007352433472

50 NR

28.4x24.4x11.9 [cm]

1,059 [g]

8007352716544

300 NR

59.5x38.5x26.5 [cm]

6,354 [g]
