1P 16AX reversing switch Next - 20013.N

Pdf
Vimar - 20013.N - 1P 16AX reversing switch Next
Vimar - 20013.N - 1P 16AX reversing switch Next
20013.N

Eikon Next / Devices / Basic devices

1P 16AX reversing switch Next
1P 16 AX 250 V~ reversing switch,lightable, replaceable button, Next. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
36,15 mm
Built-in depth
25,00 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IRAM - Argentina

28. NSW / RCM - Australia

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352285712
1 NR
4.1x2.8x5.3 [cm]
33.87 [g]
Barcode Qty 50 NR
8007352285729
50 NR
21.4x11.6x14.2 [cm]
1,787.8 [g]
Barcode Qty 500 NR
8007352640719
500 NR
57.5x22.5x30 [cm]
18,370 [g]
