2P 10AX 2-way switch fan coil grey - 20063

Download as PDF PDF Add to portfolio
Immagine 20063
download product photo

20063
Wiring devices / Traditional wiring devices / EIKON / Devices

2P 10AX 2-way switch fan coil grey
2P 10 AX 250 V~ switch for fan coil (6 terminals), with two buttons and central OFF position, grey. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Other
Operating method
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
No
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Label space/information surface
No
Lighting
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 V
Rated current
10,00 A
Switching current for fluorescent lamps
10
Monitoring contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
22,30 mm
Device height
49,00 mm
Device depth
43,50 mm
Built-in depth
34,00 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

20. IQC - Argentina

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352720893
1 NR
5.1x2.8x5.3 [cm]
43.4 [g]
Barcode Qty 10 NR
8007352720909
10 NR
14.4x11.6x6 [cm]
472.87 [g]
Barcode Qty 120 NR
8007352720916
120 NR
36.5x33x13.5 [cm]
6,094.44 [g]
