2P 16(3)A 1-way switch +key greyCode 20083

Download as PDFPDF

20083: Wiring devices / Traditional wiring devices / EIKON / Devices
2P 16(3)A 1-way switch +key grey: Independent mounting 2P 16(3) A 250 V~ key-operated 1-way switch, with removable key in both positions, grey. To be installed with the appropriate accessories from the Eikon series. Protection degree: IP20, Degree of pollution: II, Overvoltage category: III, for conductors from 1.5 mm2 to 4 mm2, complete circuit disconnection, Tracking index: PTI250, Glow wire 850°C
Product Status: 3 - Active

Drawings

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Switch 2-pole

Operating method
Key

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
0

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Label space/information surface
Yes

Lighting
No

Function lighting
Other

Type of lighting
Other

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Monitoring contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
22,30 mm

Device height
49,00 mm

Device depth
43,50 mm

Built-in depth
33,50 mm

00. CE Marking - EU

14. TSE - Turkey

20. IQC - Argentina

31. TISI - Thailand

37. Marking - Morocco

Minimum order quantity: 10 NR

Barcode

8007352253407

5.1x2.8x5.3 [cm]

53.13 [g]

8007352253414

10 NR

14.4x11.6x6 [cm]

575.2 [g]
