NFC/RFID switch for Mifare greyCode 20469

Download as PDFPDF

20469: Wiring devices / Traditional wiring devices / EIKON / Devices
NFC/RFID switch for Mifare grey: NFC/RFID electronic transponder card reader for installation inside the room, compatible with Mifare Electronic Solutions for Hotels, vertical pocket, 1 relay output 10 A 230 V~ NO (NON SELV), 1 relay output 4 A 230 V~ NO (NON SELV), power supply 120-230 V~ 50/60 Hz, visible in darkness pocket lighting, grey - 3 modules. Supplied without Mifare card (badge)
Product Status: 3 - Active

Sheets, Manuals, Documentation

Multilanguage instructions sheet (978 kb)

Drawings

Class group
Alarm installations, emergency call and signalling

Class
Access control system component

Standalone
Yes

Networkable
No

PC-binding
No

Type of interface
None

Type of reading technique
Data medium

Signalling
Buzzer

Mounting method
Flush-mounted

Operating voltage AC 50 Hz
120,00 - 230,00 V

Operating voltage AC 60 Hz
120,00 - 230,00 V

Operating temperature
0 - 40 °C

Degree of protection (IP)
IP20

Colour
Grey

Material
Plastic

Width
67,30 mm

Height
49,00 mm

Depth
50,00 mm

37. Marking - Morocco

92. RoHS UAE

Minimum order quantity: 1 NR

Barcode

8007352623941

5.2x5.7x7.6 [cm]

97.4 [g]

8007352623958

21.4x11.6x6 [cm]

543.2 [g]

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
