20478.N

Eikon Next / Systems / By-alarm

By-alarm - Activator 1M Next
By-alarm connector/splitter, 4 LEDs for system control and management, 1 LED for location in the dark, Next

Product Status
2 - Will be discontinued

Class group
Alarm installations, emergency call and signalling
Class
Switchgear for danger detection system
Engaging electronically
Yes
Engaging mechanical
No
Engaging biometrical
No
Engaging indication
Yes
Radio system
No
Degree of protection (IP)
IP40
Material
Plastic
Height
490.000,00 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352548527
1 NR
5.1x4.3x5.3 [cm]
32.4 [g]
Barcode Qty 5 NR
8007352548534
5 NR
14.4x11.6x6 [cm]
210 [g]
Barcode Qty 60 NR
8007352647534
60 NR
36.5x33x13.5 [cm]
2,940 [g]
Question: Can I associate a connector art.20478/19478/14478 to different areas?
Answer: Yes. With this configuration it is not possible to manage INT, PAR activations. The connector will only set ON and deactivate the areas for which it is enabled.
Question: The connector art.20478/19478/14478 continues to trigger a “tamper” alarm on the system.
Answer: If enabled, check that the mechanical contact, positioned at the rear of the product (inside the box), is correctly closed. If the mechanical tamper is not used, disable the function using the “Connectors programming” procedure indicated in the product instruction sheet.
