Vimar - 20583 - Speaker connector grey

20583

Eikon / Systems / Stereophonic sound systems

Speaker connector grey
Spring connector for speaker, grey

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data
• Ask a question

Sheets, Manuals, Documentation

• Sound System technical catlogue - IT (32460 kb)
• Instruction sheet (609 kb)

Video

• Sound system

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Insert/cover for communication technolog

Assembly arrangement
Modular device for domestic switching devices

Utilization
Other

Support ring
No

With dust cover
No

With imprint
Yes

Mounting method
Flush mounted (plaster)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (akin)
7024

Transparent
No

Type of fastening
Engage (snap)

Number of modules (module syst
1

With strain relief
No

Luster terminal
No

Suitable for degree of protect
IP20

Width of device
22,30 mm

Height of device
49,00 mm

Depth of device
29,90 mm

00. CE Marking - EU

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352400627

1 NR

5.1x4.3x5.3 [cm]

20.35 [g]

8007352400634

10 NR

26.9x11.6x4.9 [cm]

270.07 [g]

8007352648296

200 NR

47.5x27x29 [cm]

5,920 [g]
